Description
This Media Converter 1000 is used to transmit and receive data through optical fiber, which can effectively improve the data rate and ensure a stable state during use. It is widely used in large comprehensive buildings, as well as places such as governments or companies, and has the effect of safe connection. In addition, it has strong anti-interference ability and can achieve high-speed and stable signal conversion.
Features
Our Media Converter 1000 has stable and reliable performance, and its design conforms to the Ethernet standard, which is especially suitable for the fields requiring high reliability data transmission. At the same time, it uses plug and play mode, so you only need to plug in the optical port and RJ45 port, and it will work immediately. In addition, it can easily monitor the network status and support a wide operating temperature range, making it an ideal device for indoor and outdoor use.
Our service
Our Media Converter 1000 is highly praised by our customers for its high performance, reliability and innovation. Our belief is to care for products with our heart, and we have been working hard to fulfill this oath, passing on value honor, trust and respect, mission commitment to employees, passing on equal cooperation and sincere reciprocity to partners, and passing on health, friendship, and sincere feedback to the society . The company fully fulfills its responsibilities and obligations in accordance with the terms of the contract, and has won unanimous praise from all walks of life with its outstanding performance and good brand image.
Product Specification
Product Name | 10/100/1000M Fiber Media Converter |
Model | HR900WS-GE |
Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x Flow Control, IEEE 802.1af DTE Power via MDI |
Wavelength | Single Mode: 1310nm,1550nm |
Port | One RJ45 port, One SFP port |
Network Media | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter) |
Forward Mode | Store and forward |
LED Indicator | PWR: Green Illuminated to indicate unit is operating under normal operation FX Link/ACT: Green Illuminated indicates receiving link pulses from compliant fiber device and flashes when data being sent / received TP/FDX: Lit when TP full-duplex mode is active. Off when TP half-duplex mode is active. Blinks when collision signal is present. |
Power Supply | DC5V2A |
Environmental requirements | Operating Temperature: -20°C~80°C |
Transmission Distance | Fiber: Single Mode,20km; UTP: Cat.5/6, 100m |
Physical Characteristics | Dimension: 94×70×26mm(external),140×110×29mm(internal) Weight: 0.35kg(internal),0.35kg(external) Color: Metal, Black |
Warranty | 2 years |
Application
QA&QC
Storage,Handling and Transportation
Strategic partner with Babaolu
Why choose us?
- With us, you can expect top-of-the-line Fiber Media Converters at reasonable prices.
- Our Media Converter 1000 has won the favor of consumers at home and abroad by virtue of its excellent cost performance. Its quality is stable and durable.
- Our company operates a Chinese factory that specializes in high-quality 10/100/1000M Fiber Media Converters and professional services.
- We improve the efficiency of material storage and storage and the utilization of warehouse space to meet the needs of consumers.
- Our Fiber Media Converters are an affordable and reliable investment in the longevity and efficiency of your network infrastructure.
- The company is based on technology and talents to comprehensively promote the development and transformation of the enterprise.
- Our factory produces Fiber Media Converters that meet the highest industry standards.
- Our years of development, the accumulation of the formation of loyalty, responsibility, diligence, professionalism is our spiritual wealth and source of motivation.
- Our company takes the manufacturing of Fiber Media Converters seriously and implements strict quality control measures.
- We always put service first in our work. If you encounter any questions, you can consult and give feedback to us. We promise to respond promptly and accurately to customer requirements, and we are committed to continuously improving service quality.
Hot Tags: media converter 1000, China media converter 1000 manufacturers, suppliers, factory, 12 port fiber optic terminal box, coaxial fiber, Outdoor Fiber Splitter, foot jumper, duplex fiber, netlink
